Genesys 500kVA Diesel Generator – Three Phase – GEN500CT (Powered by Cummins, 415V)
Blue Diamond's 500kVA diesel generator is a cost-effective, efficient and robust unit built for serious power demands. Fitted with a Cummins QSZ13-G3 engine paired with a Stamford S4L1D-G41 alternator, this generator delivers reliable standby and prime power performance across large-scale commercial, industrial and infrastructure applications. Fully enclosed with a sound-attenuating canopy, water-cooled operation and a 1130L fuel tank, it's built to run hard in demanding Australian conditions.
Dimensions & Weight
- Length: 4500mm
- Width: 1600mm
- Height: 2500mm
- Dry Weight: 5750kg
Optional Extras
Automatic Transfer Switch ATS- can be attached to your diesel generator and allows for automatic switching from your mains power to your standby/backup generator supply.
Warranty
Covered by national warranty 2 years - 1000 hours. with service agents throughout Perth, Melbourne, Brisbane, Adelaide, Sydney.
Delivery
We can ship direct to you Australia wide. Alternatively, you can pick up from one of our sales offices located in Perth or Melbourne.
Contact Us
It's important to ensure you select the right generator for your needs. So if you have any questions or need some help please do not hesitate to call us on 1300 854 347.
Powered by Cummins QSZ13-G3 engine, trusted globally for reliability and longevity
Stamford S4L1D-G41 alternator for stable, clean power output
1130L fuel tank capacity for extended run times without refuelling
Water-cooled, turbocharged and charge air cooled, performs in hot conditions
Fully enclosed sound-attenuating canopy, 85dB(A) at 7m
ComAp MRS16 controller with remote start capability
3-phase, 4-wire 415V output with 3x15A + 1x32A outlets
Compatible with Automatic Transfer Switch (ATS) for seamless mains changeover
2 years / 1000 hours warranty with service agents nationally
Speak with a Blue Diamond Expert
Our team will ensure you are getting the right equipment for your fleet or project. Contact us today for expert advice.
- Powered by Cummins QSZ13-G3 engine, trusted globally for reliability and longevity
- Stamford S4L1D-G41 alternator for stable, clean power output
- 1130L fuel tank capacity for extended run times without refuelling
- Water-cooled, turbocharged and charge air cooled, performs in hot conditions
- Fully enclosed sound-attenuating canopy, 85dB(A) at 7m
- ComAp MRS16 controller with remote start capability
- 3-phase, 4-wire 415V output with 3x15A + 1x32A outlets
- Compatible with Automatic Transfer Switch (ATS) for seamless mains changeover
- 2 years / 1000 hours warranty with service agents nationally
- Alternator - Stamford S4L1D-G41
- Voltage: 415V
- Frequency: 50Hz
- Power Factor: 0.8
- Phase: Three Phase, 4 Wire
- Outlets: 3x15A + 1x32A
- Engine Make: Cummins
- Engine Model: QSZ13-G3
- Standby Rating: 500kVA
- Fuel Tank: 1130L
- Fuel Consumption at 75% Load: 74L/hr
- Controller: ComAp MRS16
- Noise Level: 85dB(A) at 7m
