Mine Spec Piston Air Compressor- Diesel, 11 HP 42 CFM
Mine Spec Inclusions:
E-Stop (New Fuel Pump & Labour)
Local Certified Relief Valve
Blue Diamond’s Professional Series Range of Piston Air Compressors are unbeatable value and backed by a 24 month warranty. Piston Air Compressor or Reciprocating air compressors are designed for continuous duty. They are robust and functional and have low maintenance costs.
Blue Diamond’s range of Genesys piston air compressors and are backed by a generous 2 year – 500 hour warranty for your piece of mind.
Compressor Key Features
- Model: BD2090TD
- Pump: BD3065A
- Designed for continuous duty.
- Deep finned cast iron cylinders, cooler tubes ensuring superior heat dissipation for higher operating efficiency.
- DISPLACEMENT: CFM: 42 & 1192 L/Min
- FAD (Free Air Delivery): 30 CFM & 850 L/Min
- Compressor Drive: TWO B V-BELT
- Rpm: 935
- Totally enclosed belt guard for utmost safety.
- Air receiver, conforming to Australian Standards AS1210.
- Large canister intake filters with replaceable filter elements.
- Engine: 11 HP Diesel Engine
- Pressure: 145 PSI
- Tank size (L): 160
- Convenient manual operated drain tap located midway underside of air tank.
- Convenient oil sight glass and oil drain.
- Efficient air filter to ensure clean intake air for long service life.
- High efficiency reed valves for maximum performance.
- Noise @ 7M: 92db
- Recommended oil; 15W40
Dimensions & Weight
- Packaging dimensions: 135cm x 54cm x 115cm
- Weight: 278 KG.
Gain peace of mind knowing your Genesys Piston Air Compressor is backed by a Generous 2 year – 500 hour warranty. We offer 24/7 Australia wide support on all our Genesys Piston Air Compressor models, with service agents throughout Perth, Melbourne, Brisbane, Adelaide, Sydney.
We can ship direct to you Australia wide. Alternatively, you can pick up from one of our sales offices located in Perth or Melbourne.
Blue Diamond Machinery provides comprehensive range of air compressor servicing, preventative maintenance and compressor repair services across Perth, WA. With over 25 years of experience servicing all types of compressors our service team ensure minimum downtime, quality and reliability on all compressor service and repair work.
It's important to ensure you select the right air compressor for your needs. So if you have any questions or need some help please do not hesitate to call us on 1300 998 647
